ESMT(晶豪科技)
单通道低压差线性稳压器
EMP8966-xxVF05NRR
The EMP8966 low-dropout (LDO) CMOS linear regulators, feature ultra-high power supply rejection ratio (75dB at 1kHz), low output voltage noise (30μV), low dropout voltage (270mV), low quiescent current (110μA), and fast transient response. It guarantees delivery of 600mA output current, and supports adjustable (1.2V to 5.0V) output voltage versions.
The EMP8966 is ideal for battery-powered applications by virtue of its low quiescent current consumption and its 1nA shutdown mode of logical operation. The regulator provides fast turn-on and start-up time by using dedicated circuitry to pre-charge an optional external bypass capacitor. This bypass capacitor is used to reduce the output voltage noise without adversely affecting the load transient response. The high power supply rejection ratio of the EMP8966 holds well for low input voltages typically encountered in battery- operated systems. The regulator is stable with small ceramic capacitive loads (2.2μF typical).
Additional features include regulation fault detection, bandgap voltage reference, constant current limiting and thermal overload protection. Available in miniature 5-pin SOT-23-5,SOT-23-6 package options are offered to provide additional flexibility for different applications. EMP products is RoHS compliant.
Features
Miniature SOT-23-5 and SOT-23-6 packages
600mA guaranteed output current
75dB typical PSRR at 1kHz
30μV RMS output voltage noise (10Hz to 100kHz)
270mV typical dropout at 600mA
110μA typical quiescent current
1nA typical shutdown mode
Fast line and load transient response
80μs typical fast turn-on time
2.5V to 5.5V input range
Stable with small ceramic output capacitors
Over temperature and over current protection
±2% output voltage tolerance
Applications
Wireless handsets
PCMCIA cards
DSP core power
Hand-held instruments
Battery-powered systems
Portable information appliances
