ETA1611
The ETA1611 is a high efficiency step-up converter with an internally integrated 22V power MOSEFT. It runs with an optimal 1MHz frequency that enables the use of small external components while still providing the best efficiency. It can drive up to 2A output current. The incorporated true PWM-Diming feature through EN pin enable one further digitally program the output voltage lower. For maximum protection, the ETA1611 has an OVP protection feature that prevents the output voltage exceeding the maximum rating of the ETA1611 and the output cap during open conditions.
ETA1611 is available in a space-saving SOT23-6 package.
FEATURES
Up to 95% Efficiency
22V OVP protection
True PWM Brightness Control
200mV Feedback Voltage
2.8A current limit
SOT23-6 Package
APPLICATIONS
Portable power bank
Powering 3G module
Large LCD display backlight driving up to 90 LEDs
Satellite STB
Bluetooth Speaker
Large TFT screen bias
Other application which needs high voltage and high current generation
