ETA(钰泰半导体)
降压稳压器
ETA1468
ETA1468 is a wide input range, high-efficiency and highfrequency DC-to-DC step-down switching regulator, capable of delivering up to 2A of output current. It adopts an adaptive COT control scheme that enables very fast transient response and provides a very smooth transition when the output varies from light load to heavy load. The adaptive COT control also maintains a constant switching frequency across line and load.
ETA1468 is available in SOT23-6 package.
FEATURES
Wide Input Voltage Range: 3.5V-18V
Adaptive COT Control
Forced PWM Mode
Capable of Delivering 2A Output
Ultra-fast Load Transient Response
High Efficiency Synchronous Operation
Low Rdson Internal power FETs
No External Compensation Needed
Thermal Shutdown and UVLO
Available in SOT23-6 Package
RoHS Compliant
APPLICATIONS
LCD TV
Set Top Box
IP CAM
