降压式转换器
JW5712A
The JW5712/A provides an ultra-low power solution for products powered by either one rechargeable Li-Ion batteries, Li-primary battery chemistries such as Li-MnO2 or two to three cell alkaline batteries. The output voltage of the buck converter is set with three VSEL pins between 0.7V and 3.3V. JW5712/A features low output ripple voltage and low noise with a small output capacitor. Once the input voltage comes close to the output voltage the device enters the 100% duty cycle operation mode to prevent an increase of output ripple voltage. In this operation mode the device stops switching and turns the high-side MOSFET switch on.
JW5712/A is available in 8 ball WLCSP 1.6mmx0.9mm package, which provide a compact solution with minimal external components.
FEATURES
2.3V to 5.5V operating input range
Output current JW5712/A: 600mA, peak to 800mA
Typical 360nA quiescent current
Up to 90% efficiency with load current>15uA
Low output ripple voltage
8 selectable output voltages
JW5712: 1.2V to 3.3V
JW5712A: 0.7V to 3.1V
Output short protection
Output voltage discharge
Automatic transition to 100% duty cycle operation
Thermal protection
Available in WLCSP8 package
APPLICATIONS
IOT
Wearable and Personal Electronics
Health Monitoring and Medical Accessories
Industrial Metering
Energy Harvesting
.png)
