降压式转换器
JWH5276
The JWH5276 is a monolithic buck switching regulator based on a proprietary I2 control for fast transient response. Operating with an input range of 2.95V~7V, JWH5276 delivers 6A of continuous output current with integrated two MOSFETs. The internal synchronous power switches provide high efficiency without the use of an external schottky diode.
JWH5276 guarantees robustness with output short protection, thermal protection, current run-away protection, and input under voltage lockout.
JWH5276 is available in QFN3X3-16 packages, which provide a compact solution with minimal external components.
FEATURES
2.95V to 7V operating input range
Up to 6A output current
Internal 12mΩ High-Side and 12mΩ Low-Side MOSFETs
Adjustable switching frequency
Adjustable soft-start time
Power good indicator
Input under voltage lockout
Output short circuit protection
Thermal protection
Available in QFN3X3-16 package
APPLICATIONS
Low-voltage, High Density Power System
POL Regulation for High-performance DSPs, FPGAs, ASICs and Microprocessors
Gaming, DTV and Set-top Boxes
Hard Disk Drives
