降压式转换器
JW5392
The JW5392 and JW5392F are monolithic buck switching regulators based on I2 architecture for fast transient response. Operating with an input range of 4.5V~18V, JW5392 and JW5392F deliver 2A of continuous output current with two integrated N-Channel MOSFETs. The internal synchronous power switches provide high efficiency without the use of an external Schottky diode. At light loads, JW5392 operates in low frequency to maintain high efficiency.
JW5392 and JW5392F guarantee robustness with output short protection, thermal protection, current run-away protection and input under voltage lockout.
JW5392 and JW5392F are available in SOT563 package, which provide a compact solution with minimal external components
FEATURES
4.5V to 18V operating input range 2A output current
Up to 95% efficiency
PFM mode (JW5392) at light load
FCC mode (JW5392F) at light load
600kHz switching frequency
Internal soft-start
Input under voltage lockout
Current run-away protection
Output short protection
Thermal protection
Available in SOT563 package
APPLICATIONS
Distributed Power Systems
Networking Systems
FPGA, DSP, ASIC Power Supplies
Green Electronics/ Appliances
Notebook Computers
