降压式转换器
JW5357M
The JW5357 and JW5357M are monolithic buck switching regulator based on I2 architecture for fast transient response. Operating with an input range of 4.5V~18V, JW5357 and JW5357M deliver 3A of continuous output current with two integrated N-Channel MOSFETs. The internal synchronous power switches provide high efficiency without the use of an external Schottky diode. At light loads, JW5357 and JW5357M operate in low frequency to maintain high efficiency.
JW5357 and JW5357M guarantee robustness with output short protection, thermal protection, current run-away protection and input under voltage lockout.
JW5357 and JW5357M are available in SOT23-6 package, which provide a compact solution with minimal external components
FEATURES
4.5V to 18V operating input range 3A output current
Up to 95% efficiency
PFM at light load
600kHz switching frequency
Internal soft-start
Input under-voltage lockout
Current run-away protection
Output short protection
Thermal protection
Available in SOT23-6 package
APPLICATIONS
Distributed Power Systems
Networking Systems
FPGA, DSP, ASIC Power Supplies
Green Electronics/ Appliances
Notebook Computers
.png)
