降压式转换器
JW5361M
The JW5361M and JW5361FM are monolithic buck switching regulators based on I2 architecture for fast transient response. Operating with an input range of 4.5V~18V, JW5361M and JW5361FM deliver 3A of continuous output current with two integrated N-Channel MOSFETs. The internal synchronous power switches provide high efficiency without the use of an external Schottky diode. At light loads, JW5361M operates in low frequency to maintain high efficiency.
JW5361M and JW5361FM guarantees robustness with output short protection, thermal protection, current run-away protection and input under voltage lockout.
JW5361M and JW5361FM are available in SOT23-6 package, which provide a compact solution with minimal external components.
FEATURES
4.5V to 18V operating input range 3A output current
Up to 95% efficiency
FCCM at light load (JW5361FM)
PFM at light load (JW5361M)
600kHz switching frequency
Internal soft-start
Input under-voltage lockout
Current run-away protection
Output short protection
Thermal protection
Available in SOT23-6 package
APPLICATIONS
Distributed Power Systems
Networking Systems
FPGA, DSP, ASIC Power Supplies
Green Electronics/ Appliances
Notebook Computers
