降压式转换器
JW5393
The JW5393 and JW5393F are monolithic buck switching regulators based on I2 architecture for fast transient response. Operating with an input range of 4.5V~18V, JW5393 and JW5393F deliver 3A of continuous output current with two integrated N-Channel MOSFETs. The internal synchronous power switches provide high efficiency without the use of an external Schottky diode. At light loads, JW5393 operates in low frequency to maintain high efficiency.
JW5393 and JW5393F guarantee robustness with output short protection, thermal protection, current run-away protection and input under voltage lockout.
JW5393 and JW5393F are available in SOT563 package, which provide a compact solution with minimal external components
FEATURES
4.5V to 18V operating input range 3A output current
Up to 95% efficiency
PFM mode (JW5393) at light load
FCC mode (JW5393F) at light load
600kHz switching frequency
Internal soft-start
Input under voltage lockout
Current run-away protection
Output short protection
Thermal protection
Available in SOT563 package
APPLICATIONS
Distributed Power Systems
Networking Systems
FPGA, DSP, ASIC Power Supplies
Green Electronics/ Appliances
Notebook Computers
