降压式转换器
JW5068A
The JW5068A is a monolithic buck switching regulator based on I2 architecture for fast transient response. Operating with an input range of 4V~23V, JW5068A delivers 8A of continuous output current with two integrated N-Channel MOSFETs. The internal synchronous power switches provide high efficiency without the use of an external Schottky diode. At light loads, the regulator operates in low frequency to maintain high efficiency and low output ripples.
JW5068A guarantees robustness with output short protection, thermal protection, current run-away protection, and input under voltage lockout.
JW5068A is available in QFN3X3-20 package, which provide a compact solution with minimal external components.
FEATURES
4V to 23V operating input range 8A continuous / 16A peak output current
Up to 95% efficiency
High efficiency at light load
500kHz switching frequency
External bypass input
Programmable valley current limit
Power good indicator
Input under voltage lockout
Output discharge function
Output Over Voltage latch off protection
Output short protection
Thermal protection
RoHS Compliant and Halogen Free
Available in QFN3X3-20 package
APPLICATIONS
Industrial and commercial low power system
Notebook
LDO monitors and TVs
Green Electronics/ Appliances
