降压式转换器
JW5116F
The JW5116F is a current mode monolithic buck switching regulator. Operating with an input range of 4.7-40V, the JW5116F delivers 3A of continuous output current with an integrated high side N-Channel MOSFET. At light loads, JW5116F operates in low frequency to maintain high efficiency and low output voltage ripple. Current mode control provides tight load transient response and cycle-by-cycle current limiting. The JW5116F guarantees robustness with input under-voltage lockout, start-up current run-away protection, output short protection and thermal protection.
The JW5116F is available in SOP8 and ESOP8 package, which provides a compact solution with minimal external components.
FEATURES
4.7V to 40V operating input range 3A output current
Up to 92% efficiency
High efficiency (>78%) at light load
Internal soft-start
Adjustable switch frequency
Input under-voltage lockout
Start-up current run-away protection
Output short protection
Thermal protection
Available in SOP8 and ESOP8 package
APPLICATIONS
Distributed Power Systems
Networking Systems
FPGA, DSP, ASIC Power Supplies
Green Electronics/ Appliances
Notebook Computers
