降压式转换器
JWH5125
The JWH5125 is a current mode monolithic buck switching regulator. Operating with an input range of 4.8V~65V, the JWH5125 delivers 5A of continuous output current with an integrated high side N-Channel MOSFET. At light loads, the regulator operates in low frequency to maintain high efficiency. Current mode control provides tight load transient response and cycle-by-cycle current limit.
The JWH5125 guarantees robustness with short-circuit protection, thermal protection, current run-away protection, and input under voltage lockout.
The JWH5125 is available in DFN4x4-10 package, which provides a compact solution with minimal external components.
FEATURES
4.8V to 65V operating input range 5A output current
0.8V±1% internal voltage reference
Adjustable soft-start
Adjustable switching frequency
UV and OV power good indicator
Adjustable UVLO and hysteresis
Current run-away protection
Short circuit protection
Thermal protection
Available in DFN4x4-10 package
APPLICATIONS
Industrial Automation and Motor Control
Vehicle Accessories: GPS Entertainment
USB Dedicated Charging Ports and Battery Chargers
12-V, 24-V and 48-V Industrial, Automotive and Communications Power Systems
