ETA(钰泰半导体)
低压差线性稳压器
ETA5030*
ETA5030 is a fixed output, low-dropout (LDO) low-power linear voltage regulator which features high power-supply rejection ratio (PSRR), ultralow noise, fast start-up, and excellent line and load transient responses. Its PSRR can be as high as 70dB at 1KHz with quiescent current of about 35uA. Therefore, ETA5030 is an ideal power supply for noise-sensitive applications such as RF transmissions, cellphones, CMOS sensors and audios, etc.
ETA5030 is available in SOT23-3 package.
FEATURES
High PSRR, 73dB at 100Hz, 70dB at 1KHz
300mA Output Current
35uA Iq
Stable with a Wide Range of Ceramic Capacitor
Excellent Load and Line Transient Response
0.24V Dropout Voltage for 200mA at Vout=3.3V
Available in SOT23-3 Package
RoHS Compliant
APPLICATIONS
Cellphone
Security Camera
Set-Top Box
