ETA(钰泰半导体)
低压差线性稳压器
ETA5094*
ETA5094 is a linear regulator features wide input range, high power-supply rejection ratio(PSRR) and low noise. The device provides fixed output voltages of 3.3V and 5V.
The device also includes short circuit protection, over voltage protection and thermal shutdown. The shutdown current of ETA5094 is as low as 2uA.
Therefore, ETA5094 is an ideal power supply for power delivery, personal digital assistants, low power battery-powered applications.
ETA5094 is available in SOT89-3 package
FEATURES
Wide Input Voltage Range: From 6V to 40V
Fixed Output Voltage: 3.3V and 5V
Up to 150mA Output Current
High PSRR, 60dB
Integrated Thermal and Current Limit
APPLICATIONS
Space-Sensitive Applications
Battery-Powered Equipment
Cordless and Mobile Phones
Industrial and Medical Equipment
Portable Equipment
