低压差线性稳压器
ETA5120*
ETA5120 is a fixed output, low-dropout (LDO), low-power linear voltage regulator that features ultra-low standby current as low as 2uA. It can withstand input voltage up to 20V and deliver 200mA output current, at least. Therefore, ETA5120 is an ideal power supply for low power applications such as IoT, wearables and multi-cell battery powered system, and etc.
ETA5120 is available in SOT23-5.
FEATURES
20V Input Voltage
2uA Ultra-low IQ
200mA Output Current
Stable with a Wide Range of Ceramic Capacitor
300mV Dropout Voltage for 100mA at VOUT = 2.8V
RoHS Compliant
APPLICATIONS
NB-IoT Module
Wearables
Multi-cell Battery Powered System
