低压差线性稳压器
ETA5196
ETA5196 is a power management unit(PMU) consisting of a 24V current limit switch and a 200mA LDO linear regulator. The input operating voltage can be as high as 24V and input standoff voltage is up to 32V.
The LDO is capable of delivering up to 200mA current with a linear foldback current limit.
ETA5196 is available in SOT23-6 and SOP8 package.
FEATURES
Stable with Wide Range of Output Capacitor
Wide Input Voltage Range: 3.8V-24V
Wide Output Voltage Range of LDO: 1.1V-12V
32V Input Standoff Voltage
Dual Thermal Shutdown
SOT23-6 and SOP8 package
RoHS Compliant
APPLICATIONS
Power Meter
Power Meter Module
