ETA5197
ETA5197 is a power management unit(PMU) consisting of a 24V current limit switch and a 200mA LDO linear regulator. The input operating voltage can be as high as 24V and input standoff voltage is up to 32V. The current limit of the switch can be externally programmed by a resistor. The LDO is capable of delivering up to 200mA current with a linear foldback current limit.
ETA5197 is available in SOT23-6 package.
FEATURES
Stable with Wide Range of Output Capacitor
Wide Input Voltage Range: 3.8V-24V
Wide Output Voltage Range of LDO: 1.1-12V
32V Input Standoff Voltage
Programmable Current Limit
Dual Thermal Shutdown
SOT23-6 Package
APPLICATIONS
Power Meter
Power Meter Module
