ETA7017
The ETA7017/A is a small, low RDSON switch with controlled turn on. The device contains a PMOS that can operate over an input voltage range of 1.4V to 5.5V. The switch is controlled by an external logic pin, which is an active high enable.
The ETA7017/A contains a 65mohm on-chip resistor for quick discharge when the switch is turned off. Quiescent current and shutdown current are all less than 1uA at VIN=5.5V.
The ETA7017/A is available in a very small WLCSP 0.87x0.87-4 package.
FEATURES
Less than 1uA Quiescent and Shutdown Current
1.4V-5.5V Operating Range
Low On-Resistance, RDSON=65mohm@VIN=3.3V
Up to 2A Continuous Output Current
Output Auto Discharge
Active high EN pin
ESD Ratings: 4KV Human body mode
APPLICATIONS
NB-IOT module
Wireless communication module
