ETA8156
ETA8156 is a wide input range, high efficiency and high frequency DC to DC step-down switching regulator, capable of delivering up to 6A output current. It adopts an adaptive COT control scheme that enables very fast transient response and provides a very smooth transition when the output varies from light load to heavy load. During light load, ETA8156 goes into a PFM mode that saves switching loss achieving high efficiency. An OVP function protects the IC itself and its downstream system against input voltage surges.
ETA8156 is available in FCTSOT23-6 Package.
FEATURES
Wide Input Range: 4.5V-17V
Adaptive COT Control
Ultra-fast Load Transient Response
High Efficiency PFM Mode at Light Load
Low RDS(ON) Internal Power FETs
Capable of Delivering Up to 6A
No External Compensation Needed
Thermal Shutdown and UVLO
Output Auto-discharge Function
Available in FCTSOT23-6 Package
RoHS compliant
APPLICATIONS
LCD TV
Set Top Box
DSL Modem
