锂电池充电器

ETA4259

ETA4259 is a single cell, fully integrated constant current (CC)/constant voltage (CV) Li-ion battery charger. Its compact package with minimum external components requirement makes the ETA4259 ideal for portable applications. No external sense resistor or blocking diode is necessary for the ETA4259. Build-in thermal feedback mechanism regulates the charge current to control the die temperature during high power operation or at elevated ambient temperature. The ETA4259 has a pre-charge function for trickle charging deeply discharged batteries. The fast charge current can be programmed by an external resistor. CV regulation mode is automatically enabled once the battery’s charging curve reaches the constant voltage portion. The output current then decays and is finally terminated once the charge current drops to 1/5 of the programmed value. The ETA4259 keeps monitoring the battery voltage and enables a new charge cycle once the voltage drops by 200mV below the CV value.

ETA4259 is in an DFN3x3-10 package.

FEATURES
40V input standoff voltage
4.2V charge termination voltage
2.6V trickle charge threshold
Charge current programmable, up to 1.2A
400nA BAT current when no charging
Soft-start limits in-rush current
Fault and Charge Status Indicator
DFN3x3-10

APPLICATIONS
E-cigarette
Toys
Bluetooth applications
Li-ion battery powered devices
