锂电池充电器
ETA6002
ETA6002 is a switching Li-Ion battery charger with dynamic power-path control and input current limiting.
When a battery is connected, depending on the battery voltage, the DC-DC switching regulator either pre-conditions, fast-charges the battery or just regulates a system voltage (VSYS) to a preset voltage. It does not require an external sense resistor for current sensing. The fast-charging current is determined by programming ISET pin. When the battery voltage reaches the termination voltage i.e., 4.2V, the charging path disconnects SYS to BATT. The ETA6002 also includes a dynamic power path when the SYS load current exceeds current limit of the DCDC regulator internally set, the SYS voltage falls below VBATT, ETA6002 turns on the power-path to supplement the system load through the battery.
FEATURES
Switching Charger with Power Path Management
Up to 95% DC-DC Efficiency
50mΩ Power Path MOSFET
Up to 2.5A Max charging current
Instant on with a dead Battery or no Battery
No Battery Detection
No External Sense Resistor
Programmable Charging Current
RoHS Compliant
APPLICATIONS
Tablet, MID
Smart Phone
Power Bank
