ETA(钰泰半导体)
低压差线性稳压器
ETA5041*
ETA5041 is a low-dropout (LDO) linear voltage regulator that features ultra-low standby current as low as 2.5uA. It can withstand input voltage up to 48V and deliver 300mA output current.
ETA5041 can provide fixed or adjustable output voltages with wide input voltage range from 3V to 45V. The device also includes short circuit protection, UVLO and thermal shutdown.
Therefore, ETA5041 is an ideal power supply for low power applications such as IoT, portable and multi-cell battery-powered system, etc.
ETA5041 is housed in a tiny SOT23-5 package.
FEATURES
Wide Input Voltage Range: from 3V to 45V
Ultra-Low Quiescent Current: 2.5uA
300mA Output Current
Stable with a Wide Range of Ceramic Capacitor, Larger than 1μF
High PSRR, 70dB at 1KHz
Integrated Thermal and Current Limit
RoHS Compliant
APPLICATIONS
Portable Equipment
Multi-cell Battery-Powered System
NB-IoT Module
